3-Wheel Electric
The Toyota 3-Wheel Electric delivers the throughput needed to accelerate an operation’s performance with consistent uptime while lowering operating costs. Several new advanced features including an automatic parking brake and seatbelt interlock offer a new world of uptime, efficiency, and productivity. Plus, the 3-Wheel’s new Color LCD Multifunction Display with battery capacity, parking brake, and optional SEnS+ object detection indicators empower operators to reach new heights of efficiency and productivity. The 3-Wheel is a shining example of Toyota’s commitment to insightful, productive and efficient material handling. Standards that raise the standards — so you can spend less time on maintenance and more time getting things done.
Lead time got you down? Toyota’s 3-Wheel Electric forklift currently has the industry-best lead time. Order your 3-Wheel Electric forklift today and receive it in 15 weeks or less!
The Toyota 3-Wheel Electric Forklift is a multi-use forklift that leads the industry in run time, travel speeds and lift/lowering speeds. With 20% longer run time, 15% faster travel speeds and ZERO emissions, the ergonomically pleasing, easy to maintain 3-Wheel Electric Forklift with an optional “short” model, is an asset to any application, including narrow aisles and tight spaces.
SEnS Smart Environment Sensor™ (SEnS)
The SEnS Smart Environment Sensor™ (SEnS) pedestrian detection system – designed and engineered by Toyota – uses advanced technology and can assist operators in identifying a pedestrian or object behind their forklift during a shift. If within a detectible range, a buzzer and four indicator lights will alert the operator that a pedestrian or object is within a certain range of the rear of the forklift. SEnS is available as an add-on kit that can be retrofitted for select Toyota forklift models currently in utilization, as well as new models. SEnS, works with multiple input voltages and fits a variety of applications.
- 3,000 – 4,000 lb. capacity
- Navigation in 10-11′ aisles
- Up to 4,000 lb. Lifting Capacity
- Up to 23′ Lift height
- Turn speed control system
- Wet disc brakes
- Smooth and responsive controls
- Industry-leading travel times
- AC drive motor
- No tools required floorboard
- Overall ergonomic improvements
Toyota’s 3-Wheel Electric forklift is designed with the operator in mind. Controls are designed and positioned for easy access and intuitive functionality, enabling confident control of the forklift in forward or reverse. Add the ergonomic benefits of the smaller steering wheel, 4-way adjustable full-suspension seat, and dual side entry with assist grips. The result? Increased comfort and a more productive experience.
The 3-Wheel Electric Forklift outpaces the competition where it counts. Industry-leading acceleration and travel speed. Faster lift and lower speeds. Longer run times on a single charge and an optional lithium-ion battery to keep you out in front, where it really counts.
Warehouse navigation is simplified with the Toyota 3-Wheel Electric Forklift. You can load and unload quickly, with unsurpassed lift and lower speeds. Easily control fork placement with smooth, responsive, progressive hydraulics on the mast (faster turnarounds). And appreciate the extra assist of cornering speed control. Increased productivity
carries the day.
AC power pays off with real savings over the life of your forklift. Maintenance costs are minimal, less downtime, and there is longer run time between charges which results in more productivity. Faster acceleration, better responsiveness and controls that are more finely tuned will give operators a smoother driving experience.
- Improved ergonomics including smaller steering wheel, foot parking brake, and low step to make getting on and off forklift easier
- Energy efficiency and one-charge run time that outpaces the competition
- Lower cost of ownership over the life of the forklift
- 100% on-board programming and diagnostics through standard display for application-specific fine-tuning and faster service
- Wet disc brakes seal out debris, keep brakes running cool, and reduce wear for increased uptime and a longer lifespan
- Cornering speed control increases stability by slowing down automatically when operator attempts to take a turn too fast
- Standard 4-way adjustable full-suspension seat is wider with no hip restraints for easier entry/exit than competitors’ seats; weight adjustable for greater operator comfort
- Cowl-mounted hydraulic levers allow entering/exiting operating position from either side, saving time and driver effort
- Mast cushioning reduces bang and clang – and, more importantly, wear and tear
- Active mast control (AMC) responds automatically to enhance the stability of loads handled at high lift heights
Specifications
| Model Number | LOAD CAPACITY* (LBS.) | MAX. TRAVEL SPEED FULL LOAD (MPH) | MAX. LIFT SPEED FULL LOAD (FPM) | MAX. GRADEABILITY FULL LOAD (%) | BASIC RIGHT ANGLE STACK** (IN.) |
|---|---|---|---|---|---|
| 8FBE15U | 3,000 | 9.9 (36v Cushion/Pneumatic), 10.2 (48v) | 77 (36V), 94 (48V) | 27 | 72.1 |
| 8FBES15U | 3,000 | 9.9 (36V), 10.2 (48V) | 77 (36V), 94 (48V) | 25 | 68.9 |
| 8FBE18U | 3,500 | 9.9 (36V), 10.2 (48V) | 71 (36V), 89 (48V) | 24 | 74.2 |
| 8FBEH18U | 3,500 | 9.9 (36V), 10.2 (48V) | 71 (36V), 89 (48V) | 24 | 76.6 |
| 8FBE20U | 4,000 | 9.7 (36V), 9.9 (48V) | 67 (36V), 83 (48V) | 22 | 77.2 |
* Based on 24″ Load center
** Add load length and clearance
Product specifications may not reflect the most current product details. Contact Toyota Material Handling Solutions (TMHS) for the most current product specifications. All specifications should be verified with TMHS prior to purchase.
Performance
- 36 / 48 Volt electrical system
- AC drive and lift system
- Digital LCD multifunction display
- UL-approved model type E
- Built-In analyzer
- Self-diagnostics
- Punched plate entry/exit step
Ergonomics
- Strategically configured instrument display
- On-demand hydrostatic power steering
- Cowl-mounted hydraulic controls
- Memory-tilt steering column
- Heavy-duty slip-resistant floor mat
- Integrated switch for headlight and turn signal
- Premium, full-suspension vinyl seat
Safety
- Operator Presence Sensing System (OPSS)
- Active Mast Control (AMC)
- Load and height sensing turn speed control
- Wet Disc Brakes
- Bolt-on Overhead Guard
- Forward Tilt Lift Speed Limitation
Ease of Service
- Maintenance-free AC motors
- Battery compartment hood assist dampers
- Easy access no-tools floorboard
- Programmable maintenance timer
- Easy access controllers
- Thermal protection monitor
Optional Equipment
- Short model
- Cascade integral side shifter
- EZ pedal
- Battery slide out option
- Battery roll out option
- Mini-lever controls with Ergoshift
- Anti-static strap
- Rear assist grip with horn button
For compatibility conditions and restrictions, please contact your Toyota Material Handling Solutions or reference the forklift manual. Options may vary from illustrations provided. Details of specifications and equipment may change without notice.
| Model Number | LOAD CAPACITY* (LBS.) | MAX. TRAVEL SPEED FULL LOAD (MPH) | MAX. LIFT SPEED FULL LOAD (FPM) | MAX. GRADEABILITY FULL LOAD (%) | BASIC RIGHT ANGLE STACK** (IN.) |
|---|---|---|---|---|---|
| 8FBE15U | 3,000 | 9.9 (36v Cushion/Pneumatic), 10.2 (48v) | 77 (36V), 94 (48V) | 27 | 72.1 |
| 8FBES15U | 3,000 | 9.9 (36V), 10.2 (48V) | 77 (36V), 94 (48V) | 25 | 68.9 |
| 8FBE18U | 3,500 | 9.9 (36V), 10.2 (48V) | 71 (36V), 89 (48V) | 24 | 74.2 |
| 8FBEH18U | 3,500 | 9.9 (36V), 10.2 (48V) | 71 (36V), 89 (48V) | 24 | 76.6 |
| 8FBE20U | 4,000 | 9.7 (36V), 9.9 (48V) | 67 (36V), 83 (48V) | 22 | 77.2 |
* Based on 24″ Load center
** Add load length and clearance
Product specifications may not reflect the most current product details. Contact Toyota Material Handling Solutions (TMHS) for the most current product specifications. All specifications should be verified with TMHS prior to purchase.
- 36 / 48 Volt electrical system
- AC drive and lift system
- Digital LCD multifunction display
- UL-approved model type E
- Built-In analyzer
- Self-diagnostics
- Punched plate entry/exit step
- Strategically configured instrument display
- On-demand hydrostatic power steering
- Cowl-mounted hydraulic controls
- Memory-tilt steering column
- Heavy-duty slip-resistant floor mat
- Integrated switch for headlight and turn signal
- Premium, full-suspension vinyl seat
- Operator Presence Sensing System (OPSS)
- Active Mast Control (AMC)
- Load and height sensing turn speed control
- Wet Disc Brakes
- Bolt-on Overhead Guard
- Forward Tilt Lift Speed Limitation
- Maintenance-free AC motors
- Battery compartment hood assist dampers
- Easy access no-tools floorboard
- Programmable maintenance timer
- Easy access controllers
- Thermal protection monitor
- Short model
- Cascade integral side shifter
- EZ pedal
- Battery slide out option
- Battery roll out option
- Mini-lever controls with Ergoshift
- Anti-static strap
- Rear assist grip with horn button
For compatibility conditions and restrictions, please contact your Toyota Material Handling Solutions or reference the forklift manual. Options may vary from illustrations provided. Details of specifications and equipment may change without notice.
Download the 3-Wheel Electric Brochure
Leading travel, acceleration, lift and lower speeds make the Toyota 3-Wheel Electric forklift the best in class. Download a brochure for more information on this true multi-purpose forklift.
